22 TECHNICAL DATA
224
Fork length 816 mm (32.13 in)
Fork oil per fork leg 480 ml (16.23 fl. oz.) Fork oil (SAE 4) (48601166S1)
( p. 232)
22.8 Shock absorber
Shock absorber article number 01.18.7N.19
Shock absorber WP Performance Systems emulsion with Pro‑Lever link-
age
Spring preload
Standard 4 clicks
Static sag 20 mm (0.79 in)
Riding sag 45 mm (1.77 in)
Fitted length 364 mm (14.33 in)
22.9 Chassis tightening torques
Screw, headlight EJOT 2 Nm (1.5 lbf ft)
Screw, side stand switch M4 2 Nm (1.5 lbf ft)
Loctite
®
243™
Remaining nuts, chassis M5 4 Nm (3 lbf ft)
Remaining screws, chassis M5 5 Nm (3.7 lbf ft)
Retaining clamp, brake line M5 3 Nm (2.2 lbf ft)

KTM 690 Duke 2018 Specifications

General

Engine Type	Single-cylinder, 4-stroke
Displacement	690 cc
Torque	74 Nm @ 6, 500 rpm
Compression Ratio	12.7:1
Transmission	6-speed
Fuel System	Electronic fuel injection
Cooling System	Liquid cooled
Front Suspension	WP USD Ø 43 mm
Rear Suspension	WP Monoshock
Seat Height	835 mm
Dry Weight	148.5 kg
Fuel Capacity	14 liters
Bore x Stroke	105 mm x 80 mm
Starter	Electric starter
Front Wheel	3.50 x 17"
Rear Wheel	5.00 x 17"
Front Tire	120/70 ZR 17
Rear Tire	160/60 ZR 17
Power	73 hp (54 kW) @ 8, 000 rpm
Front Brake	Brembo four-piston radial caliper, 320 mm disc
Rear Brake	Brembo single-piston floating calliper, brake disc Ø 240 mm
ABS	Bosch 9M+ Two Channel ABS
Frame	Chromium-Molybdenum steel trellis frame, powder-coated
