KTM 690 Duke 2018 User Manual

22 TECHNICAL DATA
214
Starting aid Electric starter, automatic decompressor
22.2 Engine tightening torques
Screw, membrane fixation M3 2 Nm (1.5 lbf ft)
Loctite
®
243™
Hose clamp, intake flange M4 2.5 Nm (1.84 lbf ft)
Oil nozzle for clutch lubrication M4 2 Nm (1.5 lbf ft)
Oil nozzle for conrod bearing lubri-
cation
M4 2 Nm (1.5 lbf ft)
Loctite
®
243™
Locking screw for bearing M5 6 Nm (4.4 lbf ft)
Loctite
®
243™
Oil nozzle in cylinder head M5 2 Nm (1.5 lbf ft)
Loctite
®
243™
Remaining screws, engine M5 6 Nm (4.4 lbf ft)
Screw, axial lock of camshaft M5 6 Nm (4.4 lbf ft)
Loctite
®
243™
Screw, clutch spring M5 6 Nm (4.4 lbf ft)
Screw, cover plate for oil return
line
M5 6 Nm (4.4 lbf ft)
Screw, gear sensor M5 5 Nm (3.7 lbf ft)
Loctite
®
243™
Screw, oil filter cover M5 6 Nm (4.4 lbf ft)

KTM 690 Duke 2018 Specifications

General

Engine Type	Single-cylinder, 4-stroke
Displacement	690 cc
Torque	74 Nm @ 6, 500 rpm
Compression Ratio	12.7:1
Transmission	6-speed
Fuel System	Electronic fuel injection
Cooling System	Liquid cooled
Front Suspension	WP USD Ø 43 mm
Rear Suspension	WP Monoshock
Seat Height	835 mm
Dry Weight	148.5 kg
Fuel Capacity	14 liters
Bore x Stroke	105 mm x 80 mm
Starter	Electric starter
Front Wheel	3.50 x 17"
Rear Wheel	5.00 x 17"
Front Tire	120/70 ZR 17
Rear Tire	160/60 ZR 17
Power	73 hp (54 kW) @ 8, 000 rpm
Front Brake	Brembo four-piston radial caliper, 320 mm disc
Rear Brake	Brembo single-piston floating calliper, brake disc Ø 240 mm
ABS	Bosch 9M+ Two Channel ABS
Frame	Chromium-Molybdenum steel trellis frame, powder-coated
