KTM 690 Enduro R User Manual

20 TROUBLESHOOTING 172
Faults Possible cause Action
Engine has too little power. Map‑Select switch incorrectly adjusted – Adjust the engine characteristic. ( p. 153)
Engine overheats. Too little coolant in cooling system – Check the cooling system for leakage.
– Check the coolant level. ( p. 148)
Radiator fins very dirty – Clean radiator fins.
Foam formation in cooling system – Drain the coolant. ( p. 149)
– Fill/bleed the cooling system. ( p. 150)
Buckled or damaged radiator hose – Change the radiator hose.
Thermostat is faulty – Check the thermostat.
Fuse 4 blown – Change the fuses of individual power consumers.
( p. 135)
Defect in radiator fan system – Check the radiator fan system.
Air in cooling system – Fill/bleed the cooling system. ( p. 150)
FI warning lamp (MIL) lights/flashes Defect in fuel injection system – Read out the fault memory using the KTM diag-
nostics tool.
N The idling speed indicator lamp does
not light up when the transmission is
in neutral
Gear position sensor not programmed – Read out the fault memory using the KTM diag-
nostics tool.
Engine dies during the journey Lack of fuel – Refuel. ( p. 56)
Fuse 1, 2 or 3 blown – Change the fuses of individual power consumers.
( p. 135)
The ABS warning lamp lights up The ABS fuse is blown – Change the ABS fuses. ( p. 133)
Large difference in wheel speeds of the
front and rear wheels
– Stop the vehicle, switch off the ignition, and
start it again.
Malfunction in ABS – Read out the ABS fault memory using the KTM
diagnostics tool.

KTM 690 Enduro R Specifications

General

Engine Type	Single cylinder, 4-stroke
Bore x Stroke	105 mm x 80 mm
Torque	73.5 Nm @ 6, 500 rpm
Compression Ratio	12.7:1
Starter	Electric starter
Transmission	6-speed
Cooling	Liquid cooled
Lubrication	Forced oil lubrication with 2 oil pumps
Primary Drive	40:76
Suspension Travel Front	250 mm
Suspension Travel Rear	250 mm
Wheels Front	1.85 x 21"
Wheels Rear	2.50 x 18"
Tires Front	90/90-21
Tires Rear	140/80-18
Chain	X-Ring 5/8 x 1/4"
Seat Height	910 mm
Fuel Tank Capacity	13.5 l
Dry Weight	146 kg
Power	74 hp (55 kW) @ 8, 000 rpm
Fuel System	Keihin EFI (Electronic Fuel Injection)
Clutch	hydraulically actuated
Frame	Chrome-molybdenum steel trellis frame, powder coated
Front Suspension	WP XPLOR USD, Ø 48 mm
Rear Suspension	WP XPLOR
Front Brake	Brembo
Rear Brake	Brembo single piston caliper, 240 mm disc
ABS	Bosch 9.1 MP (disengageable)
Wheelbase	1, 502 mm ± 10 mm
