22 TECHNICAL DATA 183

Screw, thermostat case M6x20 10 Nm (7.4 lbf ft) Loctite

243™

Screw, timing chain guide rail M6x30 10 Nm (7.4 lbf ft) Loctite

2701™

Screw, timing chain tensioning rail M6x30 10 Nm (7.4 lbf ft) Loctite

2701™

Screw, valve cover M6 10 Nm (7.4 lbf ft) –

Screw, water pump cover M6x30 10 Nm (7.4 lbf ft) –

Screw, water pump impeller M6x15 10 Nm (7.4 lbf ft) Loctite

243™

Oil jet, piston cooling M6x0.75 4 Nm (3 lbf ft) Loctite

243™

Screw plug, crankshaft clamp M8 20 Nm (14.8 lbf ft) –

Stud, exhaust flange M8 10 Nm (7.4 lbf ft) Loctite

243™

Cylinder head screw M10 Tightening sequence:

Tighten diagonally, beginning

with the rear screw on the

timing chain shaft.

Step 1

15 Nm (11.1 lbf ft)

Step 2

30 Nm (22.1 lbf ft)

Step 3

45 Nm (33.2 lbf ft)

Step 4

60 Nm (44.3 lbf ft)

Lubricated with engine oil

Oil line for oil pressure sensor M10x1 10 Nm (7.4 lbf ft) –

Oil pressure sensor M10x1 10 Nm (7.4 lbf ft) –

Plug, drain hole of water pump M10x1 15 Nm (11.1 lbf ft) –

Screw plug, oil channel M10x1 15 Nm (11.1 lbf ft) Loctite

243™

Screw plug, oil channel, for oil radiator M10x1 15 Nm (11.1 lbf ft) –

Questions and Answers:

Need help?

Do you have a question about the KTM 690 Enduro R and is the answer not in the manual?

KTM 690 Enduro R Specifications

General

Engine Type	Single cylinder, 4-stroke
Bore x Stroke	105 mm x 80 mm
Torque	73.5 Nm @ 6, 500 rpm
Compression Ratio	12.7:1
Starter	Electric starter
Transmission	6-speed
Cooling	Liquid cooled
Lubrication	Forced oil lubrication with 2 oil pumps
Primary Drive	40:76
Suspension Travel Front	250 mm
Suspension Travel Rear	250 mm
Wheels Front	1.85 x 21"
Wheels Rear	2.50 x 18"
Tires Front	90/90-21
Tires Rear	140/80-18
Chain	X-Ring 5/8 x 1/4"
Seat Height	910 mm
Fuel Tank Capacity	13.5 l
Dry Weight	146 kg
Power	74 hp (55 kW) @ 8, 000 rpm
Fuel System	Keihin EFI (Electronic Fuel Injection)
Clutch	hydraulically actuated
Frame	Chrome-molybdenum steel trellis frame, powder coated
Front Suspension	WP XPLOR USD, Ø 48 mm
Rear Suspension	WP XPLOR
Front Brake	Brembo
Rear Brake	Brembo single piston caliper, 240 mm disc
ABS	Bosch 9.1 MP (disengageable)
Wheelbase	1, 502 mm ± 10 mm
