SERVICE WORK ON THE CHASSIS 13
175
F01914-11
–
Position the retaining plate for the brake line
1
.
–
Mount and tighten screws
2
.
Guideline
Remaining screws,
chassis
M6 10 Nm (7.4 lbf ft)
13.5 Removing the passenger seat
F01915-10
–
Insert the ignition key in seat lock
1
and turn it clockwise.
– Raise the front of the passenger seat, pull it toward the tank,
and take off from above.
– Remove the ignition key from the seat lock.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the KTM 790 Adventure 2019 and is the answer not in the manual?

KTM 790 Adventure 2019 Specifications

General IconGeneral
Displacement799 cc
Transmission6-speed
Fuel Tank Capacity20 liters
Weight189 kg (dry)
Rear SuspensionWP monoshock
Rear Brake260 mm disc, 2-piston caliper
Ground Clearance233 mm
InstrumentationTFT display
StarterElectric
Fuel SystemElectronic Fuel Injection
Engine TypeLiquid-cooled, 4-stroke, parallel twin
Power95 hp (70 kW) @ 8, 000 rpm
Torque88 Nm
Seat Height850 mm
Front SuspensionWP USD Ø 43 mm
ABSBosch 9.1 MP
Riding ModesStreet, Offroad
FrameChromium-Molybdenum-Steel frame
Front Brake2 x 320 mm discs, 4-piston calipers
Wheelbase1, 509 mm (59.4 in)
Traction ControlMTC (Motorcycle Traction Control), disengageable
