SERVICE WORK ON THE CHASSIS 13
191
13.17 Installing the right side cover
F01897-10
Main work
–
Position the right side cover with holding lug
1
on bush-
ing
2
and push backward.
The right side cover engages under the tail part.
–
Press the right side cover in the area
A
into rubber bush-
ing
3
and press into rubber bushing
B
in area
4
.
Finishing work
– Mount the front rider's seat. ( p. 177)
– Mount the passenger seat. ( p. 176)
