13 SERVICE WORK ON THE CHASSIS
204
13.24 Removing the front fender
F01924-10
–
Remove screws
1
.
–
Remove screws
2
.
– Take the fender off to the front.
Info
Pay attention to the brake lines and the cable.
13.25 Installing the front fender
F01924-11
– Position the fender.
Info
Pay attention to the routing of the brake lines and the
cable.
–
Mount screws
1
, but do not tighten yet.
Guideline
Screw, fender M5x12 5 Nm (3.7 lbf ft)
–
Mount screws
2
, but do not tighten yet.
