15 WHEELS, TIRES
252
15.8 Checking spoke tension
Warning
Danger of accidentsIncorrectly tensioned spokes impair the handling characteristic and result in sec-
ondary damage.
The spokes break due to being overloaded if they are too tightly tensioned. If the tension in the spokes
is too low, then lateral and radial run-out will form in the wheel. Other spokes will become looser as a
result.
Check spoke tension regularly, and in particular on a new vehicle. (Your authorized KTM workshop will
be glad to help.)
400694-01
Strike each spoke briefly using a screwdriver blade.
Info
The frequency of the sound depends on the spoke
length and spoke diameter.
If spokes of the same length and diameter vibrate with
a different tone, this is an indication that the spoke
tensions differ.
You should hear a high note.
» If the spoke tension differs:
Correct the spoke tension.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the KTM 790 Adventure 2019 and is the answer not in the manual?

KTM 790 Adventure 2019 Specifications

General IconGeneral
Displacement799 cc
Transmission6-speed
Fuel Tank Capacity20 liters
Weight189 kg (dry)
Rear SuspensionWP monoshock
Rear Brake260 mm disc, 2-piston caliper
Ground Clearance233 mm
InstrumentationTFT display
StarterElectric
Fuel SystemElectronic Fuel Injection
Engine TypeLiquid-cooled, 4-stroke, parallel twin
Power95 hp (70 kW) @ 8, 000 rpm
Torque88 Nm
Seat Height850 mm
Front SuspensionWP USD Ø 43 mm
ABSBosch 9.1 MP
Riding ModesStreet, Offroad
FrameChromium-Molybdenum-Steel frame
Front Brake2 x 320 mm discs, 4-piston calipers
Wheelbase1, 509 mm (59.4 in)
Traction ControlMTC (Motorcycle Traction Control), disengageable
