22 TECHNICAL DATA 95
22.7.2 SX‑F USA
Fork part number 14.18.7N.59
Fork WP Suspension Up Side Down 4860 MXMA CC
Compression damping
Comfort 14 clicks
Standard 12 clicks
Sport 10 clicks
Rebound damping
Comfort 14 clicks
Standard 12 clicks
Sport 10 clicks
Spring length with preload spacer(s) 490 mm (19.29 in)
Spring rate
Weight of rider: 65… 75 kg (143… 165 lb.) 4.8 N/mm (27.4 lb/in)
Weight of rider: 75… 85 kg (165… 187 lb.) 5.0 N/mm (28.6 lb/in)
Weight of rider: 85… 95 kg (187… 209 lb.) 5.2 N/mm (29.7 lb/in)
Gas pressure 1.2 bar (17 psi)
Fork length 940 mm (37.01 in)
Oil capacity per cartridge 195 ml (6.59 fl. oz.) Fork oil (SAE 4) (48601166S1) ( p. 100)
Oil capacity fork leg without
cartridge
390 ml (13.19 fl. oz.) Fork oil (SAE 4) (48601166S1) ( p. 100)
22.7.3 SX‑F Factory Edition
Fork part number 24.18.7O.57
Fork WP Suspension Up Side Down 4860 4CS
Compression damping
Comfort 17 clicks
Standard 15 clicks
Sport 13 clicks
Rebound damping
Comfort 17 clicks
Standard 15 clicks
Sport 13 clicks
Spring length with preload spacer(s) 480 mm (18.9 in)
Spring rate
Weight of rider: 65… 75 kg (143… 165 lb.) 4.6 N/mm (26.3 lb/in)
Weight of rider: 75… 85 kg (165… 187 lb.) 4.8 N/mm (27.4 lb/in)
Weight of rider: 85… 95 kg (187… 209 lb.) 5.0 N/mm (28.6 lb/in)
Fork length 940 mm (37.01 in)
Oil capacity per fork leg 680 ml (22.99 fl. oz.) Fork oil (SAE 4) (48601166S1) ( p. 100)
22.7.4 XC‑F
Fork part number 24.18.7N.77
Fork WP Suspension Up Side Down 4860 4CS
Compression damping
Comfort 15 clicks
Standard 13 clicks
Sport 11 clicks
Rebound damping
Comfort 15 clicks
Standard 13 clicks
