1 MEANS OF REPRESENTATION 2
1.1 Symbols used
The meaning of specific symbols is described below.
Indicates an expected reaction (e.g. of a work step or a function).
Indicates an unexpected reaction (e.g. of a work step or a function).
Indicates a page reference (more information is provided on the specified page).
Indicates information with more details or tips.
Indicates the result of a testing step.
Indicates a voltage measurement.
Indicates a current measurement.
Indicates a resistance measurement.
1.2 Formats used
The typographical formats used in this document are explained below.
Proprietary name Indicates a proprietary name.
Name
®
Indicates a protected name.
Brand™ Indicates a brand available on the open market.
Underlined terms Refer to technical details of the vehicle or indicate technical terms, which are explained
in the glossary.

KTM Super Adventure 2016 Specifications

General

Displacement	1195 cc
Power	160 hp
Transmission	6-speed
Weight	238 kg
Fuel System	Electronic fuel injection
ABS	Bosch 9ME Combined ABS
Wheelbase	1560 mm
Torque	125 Nm
Fuel Capacity	30 l
Seat Height	860 mm
Front Suspension	WP USD Ø 48 mm
Front Brakes	Twin 320 mm discs
Rear Brakes	Single 267 mm disc
Front Brake	2 x Brembo four-piston radial calipers, 320 mm discs
Rear Brake	Brembo two-piston caliper
Traction Control	Motorcycle Traction Control (MTC)
Engine Type	Liquid-cooled, 4-stroke, V-twin
