ASSEMBLY INSTRUCTIONS2
3. After assembly check
(1) Before operating or test driving the equipment,
read and understand the operator's manual.
(2) Once the equipment is fully
assembled, select a safe
place for a test run. Prevent
onlookers from approaching
the equipment.
To avoid personal injury or
death:
A Do not start engine or
operate levers from
anywhere other than the
seat.
To avoid personal injury:
A Do not bypass-start the
equipment. Short circuiting
the starter terminal runs the
risk that the equipment will
start operating or moving
unexpectedly.
UNPACKING AND CHECKING PARTS
BUnpacking Iron Crate
1. Cut off the vinyl ropes that secure the top of the ROPS
to the iron crate.
2. Take the diagonal member out of the front of the iron
crate.
3. Take the 4 pieces of bolts (M10-1.25) out of both side
of the iron crate.
4. Tie up the iron crate with a nylon band and lift up with
a hoist or fork lift. (Be careful not to damage the
tractor.)
BThe Accessories Packaged Together with
Tractor
A : B1220 / B : B1620, B1820 / C : B1820ACE
A FRONT / REAR TIRES are not included in crate.
No. DESCRIPTION
UNIT
ABC
1 STEERING WHEEL 1 1 1
2 ACCESSORY CASE 1 1 1
3 FENDER L/R 1 1 1
4SEAT 1 - 1
5 TOOL BOX - - 1
To Next Page
