Kubota B1620 Assembly Instructions

3ASSEMBLY INSTRUCTIONS
BContents of Accessory Case
A : B1220 / B : B1620, B1820 / C : B1820ACE
No. DESCRIPTION
UNIT
No. DESCRIPTION
UNIT
ABC ABC
1
OPERATOR'S MANUAL 1 1 1 12 LICENSE PLATE HOLDER - 1 -
WARRANTY STATEMENT 1 1 1 13 LIGHT ASSY. (LICENSE) - 1 -
ASSEMBLY INSTRUCTIONS 1 1 1 14 STAY (TRAILER SOCKET) - 1 -
SLOW BLOW FUSE 1 1 1 15 LIGHT ASSY. (COMB. FRONT) - 2 -
STARTER KEY 2 2 2 16 STAY (FRONT WINKER) - 2 -
2 HUB ASSY. 2 2 2
17
GRIP (YELLOW 83) 1 1 1
3 COVER (FENDER TAIL) - 2 - GRIP (BLACK 83) 1 1 1
4 TAIL COVER ASSY. 2 - 2 GRIP (ORANGE 63) 1 2 2
5
LIGHT ASSY. (COMB. REAR RH) - 1 - LEVER GRIP (MAIN GEAR SHIFT) 1 1 1
LIGHT ASSY. (COMB. REAR LH) - 1 - 18 SEAT UPPER SUPPORT - 2 -
6
STAY (TAIL COVER RH) 1 - 1 19 LICENSE HOLDER STAY - 1 -
STAY (TAIL COVER LH) 1 - 1
20
SEAT STAY RH 1 - 1
7
STAY (TAIL LIGHT COVER RH) - 1 - SEAT STAY LH 1 - 1
STAY (TAIL LIGHT COVER LH) - 1 - 21 SEAT COVER, OPC 1 - -
8 COVER (PTO) 1 1 1 22 PLATE, CHECK 1 1 1
9 COVER (FENDER) 2 2 2 23 STAY (LICENSE LIGHT) - 1 -
10 PAD (STEERING) 1 1 1 24 LIGHT ASSY. (HAZARD) - - 2
11
REAR FENDER STAY RH 1 - 1 25 STAY (TOOL BOX) - - 1
REAR FENDER STAY LH 1 - 1 26 DRAWBAR PIN ASSY. - - 1
