2 SPECIFICATIONS
ENGLISH
SPECIFICATIONS
SPECIFICATION TABLE
Model BX2350D
PTO power kW (PS) 13.2 (17.9) *1
Engine
Maker KUBOTA
Model D902
Type Indirect injection, vertical, water-cooled, 4-cycle diesel
Number of cylinders 3
Bore and stroke mm 72x73.6
Total displacement L 0.898
Engine gross power kW (PS) 17.1 (23.3)
Rated revolution rpm 3200
Maximum torque N-m 56.1
Battery 526RMF (12V, RC:80min, CCA:540A)
Fuel Diesel fuel No.2, Diesel fuel No.1 [below -10 C]
Capacities
Fuel tank L 25
Engine crankcase (with filter) L 3.1
Engine coolant L 2.7
Recovery tank L 0.4
Transmission case L 11.6
Dimensions
Overall length (with 3p) mm 2425
Overall width (min. tread) mm 1145
Overall height mm 2140 (Top of ROPS), 2015 (CAB)
Wheel base mm 1400
Min. ground clearance mm 170
Tread
Front mm 910
Rear mm 820
Weight kg 665 (ROPS), 805 (CAB)
Clutch N / A
Traveling
system
Tire
Front 18x8.50-10
Rear 26x12.00-12
Steering Hydrostatic type power steering
Transmission Main: Hydrostatic transmission, High-Low gear shift (2 forward, 2 reverse)
Brake Wet disk type
Min. turning radius m 2.3
Hydraulic
unit
Hydraulic control system Directional control, auto-return lever system
Pump capacity L/min. 23.5
System pressure MPa (kgf/cm ) 12.3 to 12.8 (125 to 130)
Three point hitch SAE Category 1
Three point hitch
Max. lift force
At lift points N 5390 *2
24 in. behind lift points N 3040 *2
Remote control
valve coupler (rear)
System 2 valves
Coupler ISO 7341 series A
Remote control
valve coupler
(front : Option)
System 2 valves
Coupler (nipple) ISO 7241-1 series B
