7INSTRUMENT PANEL AND CONTROLS
ENGLISH
INSTRUMENT PANEL AND CONTROLS
B Instrument Panel, Switches and Hand Controls
ILLUSTRATED CONTENTS
(1) Easy Checker(TM)............................................... 10,22
(2) Tachometer.......................................................... 23
(3) Horn button........................................................... 16
(4) Turn signal light switch.......................................... 16
(5) Head light switch................................................... 15
(6) Hazard light switch................................................ 16
(7) Position light switch.............................................. 16
(8) Fuel gauge........................................................... 22
(9) Coolant temperature gauge.................................. 23
(10) Hourmeter.......................................................... 23
(11) Key switch.......................................................... 10
