Kubota BX2380 User Manual

FRONT LOADER
Check fixation points on the body of the tractor where
the front loader must be installed.
Install the front loader frame to the frame of the tractor
as shown in the following figures.
Location Bolt/Nut Required Torque
Main frames M14 bolts or nuts
147 N⋅m
(15.0 kgf⋅m)
[108 lbf⋅ft]
(1) 6-M14 bolts
DANGER
To avoid personal injury or death:
• Make special attention when lifting the load,
keep the bucket correctly positioned to prevent
spillages.
IMPORTANT :
• Not all risks are listed.
• Refer to the front loader operator’s manual.
WEIGHT OF THE IMPLEMENTS
AS THE REAR BALLAST
WARNING
To avoid serious injury or death:
• For tractor stability and operator's safety, the
rear ballast should be added to the rear of the
tractor in the form of 3-point counter weight and
the rear wheel ballast. The amount of the rear
ballast will depend on the application.
Implement as Counter Weight
Box Blade
Approx. 190 kg (420 lbs.)
Rear Blade
Rotary Tiller
Ballast Box
IMPLEMENT LIMITATIONS FRONT LOADER
26
BX1880, BX2380, BX2680

Kubota BX2380 Specifications

General

Engine Model	D902
Displacement	54.8 cu in (0.9 L)
Engine Power	23 hp (17.2 kW)
PTO Power	17.7 hp (13.2 kW)
Transmission	Hydrostatic
Drive	4WD
Fuel Capacity	6.6 gal (25 L)
Hydraulic System	Open center
3-Point Hitch	Category I
Lift Capacity at 24"	680 lbs (308 kg)
Tire Size (Front)	18x8.5-10
Tire Size (Rear)	26x12-12
Engine Type	3-cylinder diesel
Wheelbase	55.1 in (1400 mm)
Weight	1433 lbs (650 kg)
