Kubota BX2380 User Manual

SPECIFICATIONS
SPECIFICATION TABLE
Model BX1880 BX2380 BX2680
PTO power
*1
10.2 kW
(13.7 HP)
13.2 kW
(17.7 HP)
14.5 kW
(19.5 HP)
Engine
Maker KUBOTA
Model D722 D902 D1005
Type Liquid-cooled, 4-cycle diesel
Number of cylinders 3
Bore and stroke
67x68 mm
(2.64x2.68 in.)
72x73.6 mm
(2.83x2.90 in.)
76x73.6 mm
(2.99x2.90 in.)
Total displacement
719 cm
3
(43.9 cu. in.)
898 cm
3
(54.8 cu. in.)
1001 cm
3
(61.1 cu. in.)
Engine gross power
*2
13.4 kW
(18.0 HP)
17.1 kW
(23.0 HP)
19.0 kW
(25.5 HP)
Rated revolution
55.0 r/s to 57.5 r/s
(3300 rpm to 3450 rpm)
55.0 r/s to 58.3 r/s
(3300 rpm to 3500 rpm)
Low idling revolution 1350 rpm to 1550 rpm
Maximum torque
44.9 N⋅m
(33.1 lbf⋅ft)
56.1 N⋅m
(41.4 lbf⋅ft)
60.2 N⋅m
(44.4 lbf⋅ft)
Battery 12 V, CCA: 560 A, RC: 86 min.
Fuel
Diesel fuel No.1 [below -10 ℃ (14 ℉)]
Diesel fuel No.2 [above -10 ℃ (14 ℉)]
Capacities
Fuel tank
25.0 L
(6.6 U.S.gals.)
Engine crankcase (with filter)
3.0 L
(3.2 U.S.qts.)
3.3 L
(3.5 U.S.qts.)
4.0 L
(4.2 U.S.qts.)
Engine coolant
2.9 L
(3.06 U.S.qts.)
3.1 L
(3.3 U.S.qts.)
3.3 L
(3.5 U.S.qts.)
Recovery tank
0.4 L
(0.4 U.S.qts.)
Transmission case
11.3 L
(3.0 U.S.gals.)
Dimensions
Overall length (without 3p)
2120 mm
(83.5 in.)
Overall length (with 3p)
2425 mm
(95.5 in.)
Overall width (min. tread)
1120 mm
(44.1 in.)
1145 mm
(45.1 in.)
Overall height
(with ROPS)
2080 mm
(81.9 in.)
2110 mm
(83.0 in.)
1230 mm
(48.4 in.)
(T
op of seat)
1255 mm
(49.4 in.)
(Top of seat)
1330 mm
(52.4 in.)
(Top of seat)
(Continued)
SPECIFICATION TABLE SPECIFICATIONS
BX1880, BX2380, BX2680
19
