PERIODIC SERVICE OF THE TRACTOR80
BAdjusting Brake Pedal
To avoid personal injury:
A Stop the engine, remove the key, lower the
implement to the ground, and chock the wheels
before checking brake pedal.
A Even if the brake pedal free travel is within the
limitation, adjust the brake pedal following the
procedure below.
A If you are not able to adjust, consult your local
KUBOTA Dealer.
1. Release the parking brake.
2. Loosen the RH lock nut and extend the RH turnbuckle
to the end of the thread.
3. Loosen the LH lock nut and turn the LH turnbuckle to
adjust the LH rod length so that the brake pedal free
travel is 20 mm.
4. Retighten the LH lock nut.
5. Adjust the RH rod length so that the brake pedal free
travel is 10 mm.
6. Extend the RH turnbuckle one additional turn.
7. Retighten the RH lock nut.
8. Depress the brake pedal several times and make sure
the brake pedal free travel is from 25 to 35 mm.
EVERY 200 HOURS
BReplacing Engine Oil Filter
To avoid personal injury:
A Be sure to stop the engine and remove the key
before changing the oil filter cartridge.
A Allow engine to cool down sufficiently, oil can
be hot and can burn.
1. Remove the oil filter.
2. Put a film of clean engine oil on the rubber seal of the
new filter.
3. Tighten the filter quickly until it contacts the mounting
surface.
Tighten filter by hand an additional 1/2 turn only.
4. After the new filter has been replaced, the engine oil
normally decreases a little. Make sure that the engine
oil does not leak through the seal and be sure to check
the oil level on the dipstick. Then, replenish the engine
oil up to the prescribed level.
5. Properly dispose of used oil.
A To prevent serious damage to the engine, use only a
KUBOTA genuine filter.
Proper brake
pedal free travel
25 to 35 mm on the pedal
(1) Lock nut
(2) Turnbuckle
(A) Free travel
(1) Engine oil filter
To Next Page
