Kubota BX25D-AU User Manual

4 SPECIFICATIONS OF THE LOADER
SPECIFICATIONS OF THE LOADER
LOADER SPECIFICATIONS
BUCKET SPECIFICATIONS
A LA240AU-SG means spill guard model.
LOADER MODEL LA240 LA240AU-SG
TRACTOR MODEL BX25D-AU
BOOM CYLINDER
BORE mm 40
STROKE mm 326
BUCKET CYLINDER
BORE mm 65
STROKE mm 196
CONTROL VALVE
One Detent Float Position, Two Stage Bucket Dump,
Power Beyond Circuit
RATED FLOW L/m 14
MAXIMUM PRESSURE MPa (kg/cm ) 12.3 (125)
NET WEIGHT (APPROXIMATE) kg 170 175
LOADER MODEL LA240/LA240AU-SG
MODEL SQUARE 48"
TYPE RIGID
WIDTH mm 1219
DEPTH (L) mm 495
HEIGHT (M) mm 465
LENGTH (N) mm 538
CAPACITY
STRUCK m 0.14
HEAPED m 0.17
WEIGHT kg 60
