OPERATING THE TRACTOR38
OPERATING TECHNIQUES
BDifferential Lock
To avoid personal injury due to loss of steering
control:
A Do not operate the tractor at high speed with
differential lock engaged.
A Do not attempt to turn with the differential lock
engaged.
A Be sure to release the differential lock before
making a turn in field conditions.
If one of the rear wheels should slip, step on the
differential lock pedal. Both wheels will then turn together,
reducing slippage.
Differential lock is maintained only while the pedal is
depressed.
A When using the differential lock, always slow the
engine down.
A To prevent damage to power train, do not engage
differential lock when one wheel is spinning and the
other is completely stopped.
A If the differential lock cannot be released in the above
manner, alternately press speed control pedal forward
and backward slightly.
BOperating the Tractor on a Road
To avoid personal injury:
A When traveling on road with 3-point hitch
mounted implement attached, be sure to have
sufficient front weight on the tractor to
maintain steering ability.
Observe all local traffic and safety regulations.
BOperating on a Slopes and Rough Terrain
To avoid personal injury:
A Always back up when going up a steep slope.
Driving forward could cause the tractor to tip
over backward. Stay off hills and slopes too
steep for safe operation.
A Avoid changing gears when climbing or
descending a slope.
A If operating on a slope, never disengage shift
levers to "NEUTRAL". Doing so could cause
loss of control.
A Do not drive the tractor close to the edges of
ditches or banks which may collapse under the
weight of the tractor. Especially when the
ground is loose or wet.
1. Slow down for slopes, rough ground, and sharp turns,
especially when transporting heavy, rear mounted
equipment.
2. Before descending a slope, be sure that the range
lever is in the low " " so that speed can be
controlled without using brakes.
BDirections for Use of Power Steering
1. Power steering is activated only while the engine is
running. While the engine is stopped, the tractor
functions in the same manner as tractors without
power steering.
2. When the steering wheel is turned all the way to the
stop, the relief valve is activated. Do not hold the
steering wheel in this position for a long period of time.
3. Avoid turning the steering wheel while the tractor is
stopped, or tires may wear out sooner.
4. The power steering mechanism makes the steering
easier. Be careful when driving on a road at high
speeds.
(1) Differential lock pedal (A) Press to "ENGAGE"
(B) Release to "DISENGAGE"
To Next Page
