2 SPECIFICATIONS OF THE TRACTOR
SPECIFICATIONS OF THE TRACTOR
SPECIFICATION TABLE
NOTE: * Manufacturer's estimate The company reserve the right to change the specifications without notice.
**See and check "IMPLEMENT LIMITATIONS."
Model BX25D-AU
PTO power kW (HP) 13.2 (17.7)*
Engine
Maker KUBOTA
Model D902
Type Indirect injection, vertical, water-cooled, 4-cycle diesel
Number of cylinders 3
Bore and stroke mm 72 x 73.6
Total displacement cm 898
Engine gross power kW (HP) 17.1 (23.0)
Rated revolution rpm 3200
Low idling revolution rpm 1350 to 1450
Maximum torque N-m 56.1
Battery 12V, RC: 80min, CCA: 535A
Fuel Diesel fuel No.2 [above -10 (14 )] Diesel fuel No.1 [below -10 (14 )]
Capacities
Fuel tank L 25
Engine crankcase (with filter) L 3.1
Engine coolant L 2.7
Recovery tank L 0.4
Transmission case L 11.6
Dimensions
Overall length (without 3P) mm 2170
Overall length (with 3P) mm 2490
Overall width mm 1145
Overall
height
(with ROPS) mm 2170
(with Folded ROPS) mm 1630
(Top of steering wheel)
mm
1240
Wheel base mm 1400
Min. ground clearance mm 175
Tread
Front mm 910
Rear mm 820
Weight (with ROPS) kg 690
Clutch N / A
Traveling
system
Tire
Front 18 x 8.50-10 (Turf, Bar, Ind.)
Rear 26 x 12.00-12 (Turf, Bar, Ind.)
Steering Hydrostatic type power steering
Transmission Main: Hydrostatic transmission, High-Low gear shift (2 forward, 2 reverse)
Brake Wet disk type
Min. turning radius m 2.3
Hydraulic
unit
Hydraulic control system Directional control, auto-return lever system
Pump capacity L/min. 23.5
Three point hitch SAE Category 1
Max.
lift force
At lift points N 5390**
24in. behind lift points N 3040**
PTO
Rear PTO
SAE 1-3/8, 6 splines
Revolution 1 speed (540 rpm at 3142 engine rpm)
MID-PTO
USA No.5 (KUBOTA 10-tooth) involute spline
Revolution 1 speed (2500 rpm at 3043 engine rpm)
