39OPERATING THE TRACTOR
REVERSING THE SEAT
The seat is reversible for backhoe operation. Follow the
procedure below to turn the seat around.
1. Loosen the knob nut behind the ROPS and move the
bracket left as shown in the illustration.
2. Pull the lever up as shown in the illustration to release
the seat lock.
3. Raise the seat until the seat pin comes in to the detent
notch (see illustration).
4. Turn the seat around rearward.
(A) "TRACTOR DRIVING POSITION"
(B) "BACKHOE POSITION"
(1) Bracket (A) "LEFT"
(1) Seat lock lever (A) "RELEASE"
(1) Seat pin
To Next Page
