Kubota K008-3 - Operating the Arm K008-3;U10-3

Operation
W9212-8235-4
03/2019
75
The boom moves as shown in the figure.
Operating the arm K008-3/U10-3
 To dump the arm, push the left control lever (1) forward
(figure
).
 To crowd the arm, pull the left control lever back (figure
position
).
The arm moves as shown in the figure.
