ASSEMBLY INSTRUCTIONS10
2. Stud bolts.
Stud bolts used in front and rear axle hubs should be
tightened according to the table shown below
A Stud bolts should be inserted so that side "A" (flat
side) is towards the inside and "B" (round side) is
towards the outside of the axle hub.
ASSEMBLY OF TRACTOR
BSeat
C Tools required
Spanner (12 mm) or socket with ratchet wrench and
torque wrench.
1. Remove the retainer (1) of the rear upper side.
2. Place the sheet suspension and sheet together on the
sheet support (4). Use the threaded holes "A" on the
sheet suspension and the holes "B" on the sheet
support (4) to mount them, by the bolts (M8 x 20) (5)
as shown in the photo below.
(A) "FLAT"
(B) "ROUND"
Material of
threaded hole
Unit
Diameter
N-m kgf-m ft-lbs N-m kgf-m ft-lbs
M8
(8 mm, 0.31 in.)
11.8
to
15.6
1.2
to
1.6
8.68
to
11.5
8.82
to
11.8
0.90
to
1.2
6.51
to
8.67
M10
(10 mm, 0.39 in.)
24.6
to
31.3
2.5
to
3.2
18.1
to
23.1
19.7
to
25.4
2.0
to
2.6
14.5
to
18.8
M12
(12 mm, 0.47 in.)
29.5
to
49.0
3.0
to
5.0
21.7
to
36.1
31.4 3.2 23.1
M14
(14 mm, 0.55 in.)
63.7
to
73.5
6.5
to
7.5
47.0
to
54.2
M16
(16 mm, 0.63 in.)
10.0
to
11.5
98.1
to
113
72.3
to
83.2
M18
(18 mm, 0.71 in.)
172
to
201
17.5
to
20.5
126
to
148
Cast Iron or Steel Aluminum
(1) Retainer
(2) Bolt
(3) Sheet suspension
To Next Page
