Kubota L3200 Assembly Instructions

ASSEMBLY INSTRUCTIONS30
A Make sure to tighten the rear wheels mounting bolts
and nuts with correct tightening torque for safety
reason.
A Check that the nuts of the rim are compact with the
torque of prescription.
2. Lift the tractor on rear side, and remove the safety
stand and hang down the tractor.
3. Set the chocks under the front and rear side of rear
wheels to prevent from revolving.
A Fasten up the bolts and nuts at the torque of the
specifications.
BFront Wheel
C Tightening torque
C Tools required
Socket (19 mm, 22 mm) and extension bar with impact
wrench, torque wrench, belt slings.
A Tight the rear wheel mounting bolts and nuts
diagonally as shown figure below. Retighten the all
mounting bolts and nuts securely.
1. Install the right and left front wheels to the tractor with
the tapered side of lug nut.
(4) Chocks
Front wheel nuts : 124.0 to 147.0 N-m
12.6 to 15.0 kgf-m
91.2 to 108.0 ft-lbs
Tie rod bumper bolts : 124.0 to 147.0 N-m
12.6 to 15.0 kgf-m
91.2 to 108.0 ft-lbs

Kubota L3200 Specifications

General

Engine Type	Diesel
Drive	4WD
Hydraulic System	Open center
3-Point Hitch	Category I
Engine Power	31.9 HP
Number of Speeds	8 forward and 4 reverse
PTO Horsepower	25.5 HP
Engine Model	D1703-M
Width	55.1 inches
Height	91.7 inches
