2 SPECIFICATIONS
SPECIFICATIONS
SPECIFICATION TABLE
Model
M7040SU
2WD 4WD
Engine
Model V3307-DI
Type Direct Injection, liquid cooled 4 cylinder diesel
Number of cylinders 4
Total displacement cm (cu.in.) 3331 (203)
Bore and stroke mm (in.) 94 x 120 (3.7 x 4.7)
Rated revolution rpm 2600
Low idling revolution rpm 875 to 925
Net power *1 kW (HP) 50.7 (68)
PTO power *1
(factory observed)
kW (HP) 46.2 (62)
Maximum torque
N-m (ft-lbs) /
rpm
232 (171.1) /
1300 to 1500
Battery capacity 12V, RC: 160 min, CCA 900A
Fuel tank capacity L (U.S.gals.) 70 (18.5)
Engine oil capacity L (U.S.qts.) 11 (11.6)
Coolant capacity L (U.S.qts.) 8 (8.5)
Dimensions
Overall length mm (in.) 3565 (140) 3500 (138)
Overall width
(minimum tread)
mm (in.) 1860 (73)
Overall height mm (in.) 2470 (97)
Wheel base mm (in.) 2085 (82) 2050 (81)
Tread
Front mm (in.)
1420 to 1820
(55.9 to 71.7)
1420, 1520 (55.9, 59.8)
Rear mm (in.)
1420 to 1720
(55.9 to 67.7)
Minimum ground
clearance
mm (in.)
415 (16.3)
(Fuel tank stay)
Weight kg (lbs.)
2030
(4475)
2090
(4608)
Traveling
system
Standard
tire size
Front tires 7.5-16 9.5-24
Rear tires 16.9-30
Clutch Dry single plate
Steering Hydraulic Power Steering
Braking system Multiple wet disks mechanical
Differential Bevel gears with differential lock (Rear)
