5IMPLEMENT LIMITATIONS
IMPLEMENT LIMITATIONS
The KUBOTA Tractor has been thoroughly tested for proper performance with implements sold or approved by KUBOTA.
Use with implements which are not sold or approved by KUBOTA and which exceed the maximum specifications listed
below, or which are otherwise unfit for use with the KUBOTA Tractor may result in malfunctions or failures of the tractor,
damage to other property and injury to the operator or others. [Any malfunctions or failures of the tractor resulting from use
with improper implements are not covered by the warranty.]
A Implement size may vary depending on soil operating conditions.
Tread (max. width) with farm tires
Lower link end max.
lifting capacity: W 0
Front
Rear
2WD 4WD
M7040SU
1820 mm
(71.7 in.)
1520 mm
(59.8 in.)
1720 mm
(67.7 in.)
1900 kg
(4190 lbs.)
Implement weight: W 1
and / or size
Max. Drawbar Load: W 2
Trailer loading weight: W 3 Max. capacity
2WD 4WD
M7040SU
As in the following list
(Shown on the next page)
1000 kg
(2200 lbs.)
4500 kg
(9900 lbs.)
5000 kg
(11000 lbs.)
Lower link end max, hydraulic lifting capacity.......................................W 0
Implement weight.............................................The implement's weight which can be put on the lower link: W 1
Max. drawbar load............................................W 2
Trailer loading weight.......................................The max. loading weight for trailer (without trailer's weight): W 3
