SPECIFICATIONS
SPECIFICATION TABLE
Model ZD1211-AU ZD1221R-AU ZD1221L-AU ZD1221RL-AU
Engine
Model D1105 D1305
Power kW (HP) 18.5 (24.8)
*1*2*3
21.7 (29.1)
*1*3
Type Liquid-cooled
Number of cylinders 3
Bore and stroke mm (in.)
78 × 78.4 (3.07 ×
3.09)
78 × 88.0 (3.07 × 3.46)
Total displacement cm
3
(cu. in.) 1123 (68.5) 1261 (77.0)
Rated revolution rpm 3000
Low idling revolution rpm 1400 to 1500
Fuel
Diesel fuel No.1 (below -10 ℃ (14 ℉))
Diesel fuel No.2 (above -10 ℃ (14 ℉))
Starter Electric starter with battery, glow plug, 12 V, 1.2 kW
Lubrication Forced lubrication by gear pump
Cooling Liquid with pressurized radiator
Battery SMF51R (12 V, RC:80 min, CCA:430 A)
Capacities
Fuel tank L (U.S.gals.) 49 (12.9)
Engine crankcase (with
filter)
L (U.S.qts.) 3.9 (4.1) 5.7 (6.0)
Engine coolant L (U.S.qts.) 3.5 (3.7)
Recovery tank L (U.S.qts.) 0.25 (0.26)
Transmission case includ-
ing rear axle gear case
L (U.S.qts.) 12.1 (12.8)
*4
Dimensions
Overall length mm (in.) 2260 (89.0) 2380 (93.7)
Overall width without
mower deck
mm (in.) 1510 (59.4) 1540 (60.6)
Overall
height
With ROPS
upright
mm (in.) 2000 (78.7)
With ROPS
folded
mm (in.) 1640 (64.6)
Wheelbase mm (in.) 1440 (56.7) 1560 (61.4)
Min. ground clearance mm (in.) 130 (5.12) with 60" 130 (5.12) with 72"
Tread
Front mm (in.) 1064 (41.9) 1250 (49.2)
Rear mm (in.) 1210 (47.6)
Weight (without fuel, with mower deck) kg (lbs.) 765 (1687) with 60" 780 (1720) with 60" 800 (1764) with 72" 810 (1786) with 72"
Traveling sys-
tem
Tires
Front
15 × 6.5 - 8
Smooth semi-pneumatic low profile tire
Rear
26 × 12.0 - 16
4PR turf low profile tire
Traveling
speeds
Forward mph (km/h) 0 to 10.6 (0 to 17.0)
*3
Reverse mph (km/h) 0 to 5.3 (0 to 8.5)
*3
Steering 2 - hand levers
(Continued)
