IMPLEMENT LIMITATIONS
The KUBOTA Machine has been thoroughly tested for proper performance with implements sold or approved by
KUBOTA.
Use with implements below may result in malfunctions or failures of the machine, damage to other property and injury
to the operator or others.
• Implements which are not sold or approved by KUBOTA
• Implements which exceed the maximum specifications listed below, or
• Implements which are otherwise unfit for use with the KUBOTA Machine
Any malfunctions or failures of the machine resulting from use with improper implements are not covered by the
warranty.
Unit
Maximum loading weight
Implement weight W1 Maximum total weight
Front axle Wf Rear axle Wr
ZD1211-AU, ZD1221R-AU
ZD1221L-AU, ZD1221RL-AU
200 kg (440 lbs.) 920 kg (2028 lbs.) 200 kg (440 lbs.) 1120 kg (2468 lbs.)
Option: When using the hitch kit.
IMPORTANT :
• Do not operate on slope when pulling loads.
• Total towed weight must not exceed combined weight of pulling machine, ballast and operator.
• Follow the manufacturer's recommendations for weight limits for towed equipment.
Unit
Maximum loading weight
Maximum total
weight
Tongue weight
W1
Towing capacity
W2
Front axle Wf Rear axle Wr
ZD1211-AU, ZD1221R-AU
ZD1221L-AU, ZD1221RL-AU
200 kg (440 lbs.) 630 kg (1388 lbs.) 830 kg (1829 lbs.) 30 kg (66 lbs.) 100 kg (220 lbs.)
IMPLEMENT LIMITATIONS
ZD1211,ZD1221
21
