4. For (RCK60R, RCK72R), check the label on the
gear box before adding new oil.
Label (6) (7)
Oil type Gear oil Gasoline engine oil
Capacity 0.4 L (0.42 U.S.qts.)
SAE SAE 90 SAE 10W-30
API Service Cat-
egory
More than GL-3 SH or higher
IMPORTANT :
• To prevent serious damage to gears,
bearings and oil seals, do not mix different
kinds of oil.
RCK60R, RCK72R
(1) Drain plug
(2) Check plug
(3) Oil inlet plug
(4) Gear box
(5) Check plug port
(6) Rectangular label
(7) Octagonal label
(A) Oil level is acceptable within
this range.
(B) Oil level
5. After checking, reinstall the oil inlet plug with gauge
securely.
4. Greasing
WARNING
To avoid serious injury or death:
• Be sure to stop the engine and remove the key
before greasing.
Grease the following locations.
IMPORTANT :
• Put grease into front wheel until grease
overflows from both ends of the front wheel.
(1) King pin (LH, RH)
(2) Center pin
(3) Front wheel (LH, RH)
(1) Tilt lever
MAINTENANCE EVERY 50 HOURS
