3-S3
ZD18(F) · ZD21(F) · ZD28(F), WSM
FRONT AXLE
3. TIGHTENING TORQUES
Tightening torques of screws, bolts and nuts on the table below are especially specified.
(For general use screws, bolts and nuts: See page G-8.)
W1012736
Item N·m kgf·m ft-lbs
Wheel bolt and lock nut
Wheel bracket lock nut
Center pin lock nut (Slotted nut)
20 to 25
45 to 55
40 to 80
2.04 to 2.55
4.59 to 5.61
4.08 to 8.16
14.75 to 18.44
33.19 to 40.57
29.50 to 59.00
KiSC issued 04, 2009 A
