13. FUEL SYSTEM/CARBURETOR/
FUEL PUMP/ FUEL TANK
13-10
GRAND DINK 250
JETS/SCREWS REMOVAL
Remove the main jet, needle jet holder and
needle jet.
Remove the slow jet.
Clean the removed the main jet, needle jet
holder, needle jet and slow jet with detergent
oil.
• Before removing the pilot screw, turn
the pilot screw clockwise until it seats
lightly and record the rotating turns.
Do not force the pilot screw against its
seat to avoid seat damage.

Pilot Screw
(
P.S.
)
Main Je
t
Slow Je
t
Needle Je
t
Slow Je
t
Pilot Screw
• Be sure to use clean detergent oil.

Needle Jet Holde
r
Main Je
t

KYMCO GRAND DINK 250 Specifications

General

Displacement	249.1 cc
Cooling System	Liquid-cooled
Fuel System	Electronic Fuel Injection
Transmission	CVT
Front Suspension	Telescopic fork
Rear Suspension	Dual shock absorbers
Front Brake	Disc
Rear Brake	Disc
Front Tire	120/70-12
Rear Tire	130/70-12
Seat Height	780 mm
Engine Type	4-stroke, Single-cylinder
