3. INSPECTION/ADJUSTMENT
3-1
GRAND DINK 250
SERVICE INFORMATION
GENERAL
 WARNING
•Before running the engine, make sure that the working area is well ventilated.
Never run the engine in a closed area. The exhaust contains poisonous carbon
monoxide gas, which may cause death to people.
•Gasoline is extremely flammable and is explosive under some conditions. The
working area must be well ventilated and do not smoke or allow flames or sparks
near the working area or fuel storage area.
SPECIFICATIONS
ENGINE
Throttle grip free play : 26mm
Spark plug : NGK: DPR7EA9
Spark plug gap : 0.9~1.0mm
Valve clearance : IN: 0.1mm EX: 0.1mm
Idle speed : 1700±100rpm
Engine oil capacity: Cylinder compression : 15±2kg/cm²
At disassembly : 1.1 liter Ignition timing : repeatedly
At change : 0.9 liter Coolant capacity : 1400±20cc
Gear oil capacity : Radiator capacity : 1000±20cc
At disassembly : 0.20 liter Reserve tank capacity : 400±20cc
At change : 0.18 liter
TIRE
1 Rider 2 Riders
Front 1.75kg/cm² 1.75kg/cm²
Rear 2.00kg/cm² 2.25kg/cm²
TIRE SPECIFICATION:
Front : 120/70-12
Rear : 140/70-12
TORQUE VALUES
Front axle nut : 14.868.6N-m
Rear axle nut : 107.8127.4N-m

KYMCO GRAND DINK 250 Specifications

General

Displacement	249.1 cc
Cooling System	Liquid-cooled
Fuel System	Electronic Fuel Injection
Transmission	CVT
Front Suspension	Telescopic fork
Rear Suspension	Dual shock absorbers
Front Brake	Disc
Rear Brake	Disc
Front Tire	120/70-12
Rear Tire	130/70-12
Seat Height	780 mm
Engine Type	4-stroke, Single-cylinder
