2PK/2PL/2PM/2PN-5
1-3-25
U071 Adjust DP Leading Edge Timing
Description
Adjusts the DP original scanning timing.
Purpose
Make the adjustment if there is a regular error between the leading or trailing edges of the origi-
nal and the copy image when the DP is used.
Method
1. Press the start key.
2. Press the system menu key.
3. Place an original on the DP and press the start key to make a test copy.
4. Press the system menu key.
5. Select the item to be adjusted.l
Item No. Description
Display Description
Setting
range
Initial
setting
Change in
value per step
Front Head Leading edge registration of
CCD (first side)
-32 to 32 0 0.196 mm
Front Tail Trailing edge registration of
CCD (first side)
-32 to 32 0 0.196 mm
Back Head Leading edge registration of
CCD (second side)
-45 to 45 0 0.196 mm
Back Tail Trailing edge registration of
CCD (second side)
-45 to 45 0 0.196 mm
Rotate Leading edge registration
(rotate copying)
-128 to 127 0 0.196 mm
