Kyocera ECOSYS M3040dn Service Manual

2NM/2NX/2NY/2NZ/2P0/2P6-1
2-1-4
*1: 40 ppm model only
*2: 50/60 ppm model only
*3: Basic model only
*4: HyPAS model only
*5: Without FAX model only
*6: With FAX model only
*7: 60 ppm model only
*8: 50 ppm model only
12
Toner container connect PWB
(TCONCPWB)
P.W.BOARD ASSY CONTAINER CONN
(DK-3100(U)) *1
(DK-3100(E)) *1
(DK-3100(AO)) *1
(DK-3130(U)) *2
(DK-3130(E)) *2
(DK-3130(AO)) *2
-
(302MS93042)
(302MS93022)
(302MS93052)
(302LV93062)
(302LV93042)
(302LV93072)
13 CCD PWB (CCDPWB)
P.W.BOARD ASSY CCD
(PARTS ISU ASSY SP)
-
(302NM93010)
14 LED PWB (LEDPWB)
P.W.BOARD ASSY LED
(PARTS ISU ASSY SP)
-
(302NM93010)
15 APC PWB (APCPWB)
P.B. BOARD ASSY APC
(LK-3200) *1 *8
(LK-3230) *7
-
(302NZ93010)
(302P693010)
16 PD PWB (PDPWB)
P.B. BOARD ASSY PD
(LK-3200) *1 *8
(LK-3230) *7
-
(302NZ93010)
(302P693010)
17
Thermister connect PWB
(FTHCPWB)
PARTS PWB ASSY TH CONNECT SP 302LV94220
18 Operation panel PWB (OPPWB) *3 PARTS PANEL UNIT B SP
302P094040 *5
302NZ94040 *6
No. Name used in service manual Name used in parts list Part.No.

Kyocera ECOSYS M3040dn Specifications

General

Print Technology	Laser
Print Resolution	1200 x 1200 dpi
Duplex Printing	Yes
Max Paper Size	A4
Scan Resolution	600 x 600 dpi
Output Capacity	250 sheets
Copy Resolution	600 x 600 dpi
Maximum Copy Size	A4
Operating Systems	Windows, Mac OS, Linux
Functions	Print, Copy, Scan
Print Speed	40 ppm
Scan Speed	40 ipm
Connectivity	USB 2.0, Ethernet
Warm-up Time	15 seconds
Memory	512 MB
Paper Size	A4, A5, A6, B5, Letter, Legal
Paper Weight	60-220 g/m²
Copy Speed	40 cpm
Scan Type	Color and Monochrome
