2NM/2NX/2NY/2NZ/2P0/2P6

2-2-57

4. Remove four screws and the operation

panel PWB.

5. Check or replace the operation panel

PWB and refit all the removed parts.

Figure 2-2-70

Screw

Operation panel PWB

Operation panel

assembly
