Kyocera FS-1350DN Service Manual

2H4
1-3-1
1-3 Maintenance Mode
1-3-1 Maintenance mode
The printer is equipped with a maintenance function which can be used to maintain and service the machine.
(1) Executing a maintenance item
>>Developer
Ready
Report Print >
Adjust/ >
Maintenance
>Restart
Printer
>Service >
>>Print
Status Page
>>Print Network
Status Page
>>Print
Test Page
>>Write data
 Press the MENU key.
Message display
To print a status page for service purpose.
To print a network status page.
Prints a test page which contains halftone.
To write data into a USB memory.
To initialize the developing unit. (toner install mode)
 Press the  or  key several times
until [Adjust/Maintenance >] is displayed.
Maintenance mode items
 Press the  key.
 Press the  key.
 Press the  or  key several times
until [>Service >] is displayed.
To scroll these items,
press the  or  key
repeatedly.
(See page 1-3-2)
(See page 1-3-7)
(See page 1-3-7)
(See page 1-3-7)
(See page 1-3-8)

Kyocera FS-1350DN Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	6 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Processor model	PowerPC–440F5
Maximum internal memory	1152 MB
Sound power level (standby)	30 dB
Sound pressure level (printing)	54 dB
Power supply type	AC 220 - 240 V, 50/60 Hz
Capacity cartridge	7200 sheets
Standard media sizes	(105 x 148 - 216 x 297 mm)
Power consumption (active)	484 W
Compliance industry standards	TUV/GS, CE
Number of print cartridges	1
Total input capacity	250 sheets
Maximum input capacity	800 sheets
Maximum print size	216 x 356 mm
Non-ISO print media sizes	Folio (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Power consumption (standby)	12 W
Power consumption (PowerSave)	7.1 W
Display	LCD

Weight and Dimensions

Dimensions (WxDxH)	375 x 393 x 267 mm
