Kyocera FS-1350DN Service Manual

2H4
1-4-10
(6) Black vertical streaks.
(7) Unsharpness.
(8) Gray background.
Print example Causes Check procedures/corrective measures
Adhesion of oxide to main charger
wire.
Remove the drum unit (See page 1-5-12). Slide the charger
cleaner (green) left and right 2 or 3 times to clean the charger
wire, then return it to its original position (CLEANER HOME
POSITION). Refer to the operation guide.
Defective drum unit. A streak of toner remaining on drum after printing means that
the cleaning blade (in the drum unit) is not working properly.
Replace the drum unit (See page 1-5-12).
Defective developing roller (develop-
ing unit).
Replace the developing unit (See page 1-5-11).
Print example Causes Check procedures/corrective measures
Defective paper specifications. Replace paper with the one that satisfies the paper specifica-
tion.
Defective transfer roller installation. The transfer roller must be supported by the bushes at the
both ends. Clean the bush to remove oil and debris. Replace
the transfer roller if necessary (See page 1-5-14).
Defective transfer bias output. Replace the high voltage PWB or control PWB (See page 1-5-
24 or 1-5-19).
EcoPrint mode setting. The EcoPrint mode can provides faint, unsharp printing
because it acts to conserve toner for draft printing purpose.
For normal printing, turn the EcoPrint mode off by using the
operator panel. For details, refer to the operation guide.
Print example Causes Check procedures/corrective measures
Print density setting. The print density may be set too high. Try adjusting the print
density. For details, refer to the operation guide.
Defective potential on the drum sur-
face.
Replace the drum unit (See page 1-5-12).
Defective main charger grid. Clean the main charger grid (See page 1-5-13).
Defective developing roller (develop-
ing unit).
If a developing unit which is known to work normally is avail-
able for check, replace the current developing unit in the
printer with the normal one. If the symptom disappears,
replace the developing unit with a new one (See page 1-5-11).
ABC
123
ABC
123

Kyocera FS-1350DN Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	6 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Processor model	PowerPC–440F5
Maximum internal memory	1152 MB
Sound power level (standby)	30 dB
Sound pressure level (printing)	54 dB
Power supply type	AC 220 - 240 V, 50/60 Hz
Capacity cartridge	7200 sheets
Standard media sizes	(105 x 148 - 216 x 297 mm)
Power consumption (active)	484 W
Compliance industry standards	TUV/GS, CE
Number of print cartridges	1
Total input capacity	250 sheets
Maximum input capacity	800 sheets
Maximum print size	216 x 356 mm
Non-ISO print media sizes	Folio (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Power consumption (standby)	12 W
Power consumption (PowerSave)	7.1 W
Display	LCD

Weight and Dimensions

Dimensions (WxDxH)	375 x 393 x 267 mm
