Kyocera FS-1350DN Service Manual

2H4
1-4-3
(2) Self diagnostic codes
Code Contents
Remarks
Causes Check procedures/corrective measures
0100 Backup memory device error Defective flash
memory (U10).
Replace the control PWB (See page 1-5-
19).
Defective control
PWB.
Replace the control PWB (See page 1-5-
19).
0110 Backup memory data error Defective flash
memory (U10).
Replace the control PWB (See page 1-5-
19).
Defective control
PWB.
Replace the control PWB (See page 1-5-
19).
0120 MAC address data error Defective flash
memory (U10).
Replace the control PWB (See page 1-5-
19).
0150 Control PWB EEPROM error
Detecting control PWB EEPROM (U300)
communication error.
Improper installa-
tion control PWB
EEPROM (U300).
Check the installation of the EEPROM
(U300) and remedy if necessary (See page
1-5-19).
Defective control
PWB.
Replace the control PWB (See page 1-5-
19).
0170 Billing counting error Defective control
PWB.
Replace the control PWB (See page 1-5-
19).
0420 Paper feeder communication error
Communication error between control
PWB and optional paper feeder.
Improper installa-
tion paper feeder.
Follow installation instruction carefully again.
Defective harness
between control
PWB (YC318) and
paper feeder inter-
face connector, or
improper connec-
tor insertion.
Reinsert the connector. Also check for conti-
nuity within the connector harness. If none,
remedy or replace the harness.
Defective control
PWB.
Replace the control PWB (See page 1-5-
19).
Defective harness
between PF main
PWB (YC5) and
paper feeder inter-
face connector, or
improper connec-
tor insertion.
Reinsert the connector. Also check for conti-
nuity within the connector harness. If none,
remedy or replace the harness (Refer to the
service manual for the paper feeder).
Defective PF main-
PWB.
Replace the PF main PWB (Refer to the ser-
vice manual for the paper feeder).

Kyocera FS-1350DN Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	6 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Processor model	PowerPC–440F5
Maximum internal memory	1152 MB
Sound power level (standby)	30 dB
Sound pressure level (printing)	54 dB
Power supply type	AC 220 - 240 V, 50/60 Hz
Capacity cartridge	7200 sheets
Standard media sizes	(105 x 148 - 216 x 297 mm)
Power consumption (active)	484 W
Compliance industry standards	TUV/GS, CE
Number of print cartridges	1
Total input capacity	250 sheets
Maximum input capacity	800 sheets
Maximum print size	216 x 356 mm
Non-ISO print media sizes	Folio (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Power consumption (standby)	12 W
Power consumption (PowerSave)	7.1 W
Display	LCD

Weight and Dimensions

Dimensions (WxDxH)	375 x 393 x 267 mm
