Kyocera FS-1350DN Service Manual

2H4
1-4-8
(1) Completely blank printout.
(2) All-black printout.
Print example Causes Check procedures/corrective measures
Defective drum unit or developing
unit.
Open the top cover and check that the drum unit and develop-
ing unit are correctly seated. Investigate that the terminals
between the main charger unit and the drum unit are not in
loose contact (See page 1-5-12 and 1-5-11).
Defective transfer bias output or
developing bias output.
Replace the high voltage PWB (See page 1-5-24).
Poor contact of developing bias termi-
nal (spring) and high voltage output
terminal B (J401, J402, J403) on the
high voltage PWB.
Poor contact of transfer bias terminal
(spring) and transfer bias terminal T
(J201, J202, J203) on the high volt-
age PWB.
Check the high voltage PWB visually and correct or replace if
necessary (See page 1-5-24).
Defective laser scanner unit. Replace the laser scanner unit (See page 1-5-29).
Defective control PWB. Replace the control PWB (See page 1-5-19).
Print example Causes Check procedures/corrective measures
Defective main charger unit. Open the top cover and check that the drum unit and develop-
ing unit are correctly seated (See page 1-5-12).
Investigate that the terminals between the main charger unit
and the drum unit are not in loose contact.
Poor contact of main charger terminal
(spring) and main charger output ter-
minal M on the high voltage PWB.
Check the high voltage PWB visually and correct or replace if
necessary (See page 1-5-24).
Defective main charging output. Replace the high voltage PWB (See page 1-5-24).
Broken main charger wire. Replace the main charger unit (See page 1-5-13).
Defective control PWB. Replace the control PWB (See page 1-5-19).

Kyocera FS-1350DN Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	6 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Processor model	PowerPC–440F5
Maximum internal memory	1152 MB
Sound power level (standby)	30 dB
Sound pressure level (printing)	54 dB
Power supply type	AC 220 - 240 V, 50/60 Hz
Capacity cartridge	7200 sheets
Standard media sizes	(105 x 148 - 216 x 297 mm)
Power consumption (active)	484 W
Compliance industry standards	TUV/GS, CE
Number of print cartridges	1
Total input capacity	250 sheets
Maximum input capacity	800 sheets
Maximum print size	216 x 356 mm
Non-ISO print media sizes	Folio (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Power consumption (standby)	12 W
Power consumption (PowerSave)	7.1 W
Display	LCD

Weight and Dimensions

Dimensions (WxDxH)	375 x 393 x 267 mm
