Leica Rugby 620 User Manual

Rugby 620, Care and Transport
37
9.3 Cleaning and Drying
Product and
accessories
• Blow dust off lenses and prisms.
• Never touch the glass with your fingers.
• Use only a clean, soft, lint-free cloth for cleaning. If necessary, moisten the cloth
with water or pure alcohol. Do not use other liquids; these can attack the polymer
components.
Damp products Dry the product, the transport container, the foam inserts and the accessories at a
temperature not greater than 40°C /104°F and clean them. Remove the battery cover
and dry the battery compartment. Do not repack until everything is completely dry.
Always close the transport container when using in the field.
Cables and plugs Keep plugs clean and dry. Blow away any dirt lodged in the plugs of the connecting
cables.

Leica Rugby 620 Specifications

General

Self-leveling range	± 5°
IP rating	IP67
Working range with receiver	800 m (2, 600 ft) diameter
Rotation speed	600 rpm
Laser type	635 nm
Power source	alkaline batteries
Battery life	60 hours
Operating temperature	-20°C to +50°C
Self-leveling accuracy	± 1.5 mm at 30 m (± 1/16 in at 100 ft)
