Leica Rugby 620 User Manual

Rugby 620, Technical Data
38
10 Technical Data
10.1 Conformity to National Regulations
Conformity to
national regulations
For products which do not fall under R&TTE directive:
10.2 General Technical Data of the Laser
Operating range Operating range (diameter):
Self-levelling
accuracy
Self-levelling accuracy is defined at 25°C (77°F)
Self-levelling range
Rotation speed
Laser Dimensions
Weight
Internal battery
*Operating times are dependent upon environmental conditions.

Charging the Li-Ion battery pack takes a maximum of five hours.

Use only high quality alkaline batteries to achieve operating time.
Hereby, Leica Geosystems AG, declares that the product/s is/are in
compliance with the essential requirements and other relevant provi-
sions of the applicable European Directives. The declaration of
conformity can be consulted at http://www.leica-geosystems.com/ce.
Rugby 620: 800 m/2600 ft
Self-levelling accuracy: ±1.5 mm at 30 m (±1/16" at 100 ft)
Self-levelling range: ±5°
Rotation speed: 10 rps
005797_001
212 mm (8.4")
239 mm (9.4") 192 mm (7.6")
Rugby 620 weight with battery: 2.56 kg/5.6 lbs.
Type Operating times* at 20°C
A600 Lithium-Ion (Li-Ion Pack) 40 h
Alkaline (four D-cells) 60 h

Leica Rugby 620 Specifications

General

Self-leveling range	± 5°
IP rating	IP67
Working range with receiver	800 m (2, 600 ft) diameter
Rotation speed	600 rpm
Laser type	635 nm
Power source	alkaline batteries
Battery life	60 hours
Operating temperature	-20°C to +50°C
Self-leveling accuracy	± 1.5 mm at 30 m (± 1/16 in at 100 ft)
