Leica Rugby 620 User Manual

Rugby 620, Table of Contents
4
Table of Contents
In this manual Chapter Page
1Safety Directions
6
1.1 General 6
1.2 Definition of Use 7
1.3 Limits of Use 7
1.4 Responsibilities 7
1.5 Hazards of Use 8
1.6 Laser Classification 10
1.6.1 General 10
1.6.2 Rugby 620 10
1.7 Electromagnetic Compatibility EMC 11
1.8 FCC Statement, Applicable in U.S. 12
2 Description of the System
14
2.1 System Components 14
2.2 Rugby Laser Components 15
2.3 Case Components 15
2.4 Setup 16
3Operation
17
3.1 Buttons 17
3.2 LED Indicators 17
3.3 Turning on and off the Rugby 18
3.4 Automatic Mode 18
3.5 Manual Mode 19
3.6 Elevation Alert (H.I.) Function 20
4Receivers
21
4.1 Rod Eye 140, Classic Receiver 21
4.2 Menu - Rod Eye 140, Classic Receiver 23
4.3 Rod Eye Basic Receiver 23
5Applications
25
5.1 Setting Forms 25
5.2 Checking Grades 26
5.3 Manual Grades 27
6 Batteries
28
6.1 Operating Principles 28
6.2 Battery for Rugby 28
7Accuracy Adjustment
31
7.1 Checking the Level Accuracy 31
7.2 Adjusting the Level Accuracy 32
8Troubleshooting
34
9 Care and Transport
36
9.1 Transport 36
9.2 Storage 36
9.3 Cleaning and Drying 37

Leica Rugby 620 Specifications

General

Self-leveling range	± 5°
IP rating	IP67
Working range with receiver	800 m (2, 600 ft) diameter
Rotation speed	600 rpm
Laser type	635 nm
Power source	alkaline batteries
Battery life	60 hours
Operating temperature	-20°C to +50°C
Self-leveling accuracy	± 1.5 mm at 30 m (± 1/16 in at 100 ft)
