LONWORKS MENU TREE - CONTROL variables
DS50
R/W L [On / Off] Unit 3111
R/W L [Reset] Discharges the safety measures of the unit 3112
R/W L [BMS] Activation of the Inoccupation mode [Off] occupation mode - [On] inoccupation mode 3933
R/W L [Clock] [OFF] read hour & minute [ON] write hour & minute …
R L [Alarm] General 1000
R L [On/Off] Fan, Blower 2315
R L [On/Off] Compressor, 1 2516
R L [On/Off] Compressor, Heat pump, 1 2517
R L [On/Off] Compressor, 2 2526
R L [On/Off] Compressor, Heat pump, 2 2527
R L [On/Off] Compressor, 3 2536
R L [On/Off] Compressor, Heat pump, 3 2537
R L [On/Off] Compressor, 4 2546
R L [On/Off] Compressor, Heat pump, 4 2547
R L [On/Off] Gas, Burner, 1 2615
R L [On/Off] Gas, Burner, 2 2616
R L [On/Off] Gas, Burner, High power, 1 2617
R L [On/Off] Electrical heaters, 1 2625
R L [On/Off] Electrical heaters, 2 2626
DS50
R/W 1 = 1 s [ BMS ] Activation of the control by a computer or an automat -
mode BMS is activated if this value is different from zero,
This value is decreased every second 3932
R/W 10 = 1.0°c [Occupation][Room SP] Required maximum room temperature in °C. 3322
Cooling set point (BMS)
R/W 10 = 1.0°c [Occupation][Room SP] Required minimum room temperature in °C. 3323
Heating set point (BMS)
R/W 1 = 1% [Room SP] Required room minimum fresh air rate in %. 3312
Middle of the dead zone (BMS)
R/W 10 = 1.0°c [Inoccupation][Room SP] Required maximum room temperature in °C. 3322
Cooling set point (Uno)
R/W 10 = 1.0°c [Inoccupation][Room SP] Required minimum room temperature in °C. 3323
Heating set point (Uno)
R/W 1 = 1% [Humidity] Desired Maximum relative humidity in Room (in %). – 3341
Dehumidification set point. (BMS)
R/W 1 = 1% [Humidity] Desired Minimum relative humidity in Room (in %). – 3342
Humidification set point. (BMS)
R/W 1 = 1h [Clock] Hour 3121
R/W 1 = 1m [Clock] Minute 3122
R/W 1 = 1 [Clock] Day of the month 3123
R/W 1 = 1 [Clock] Month 3124
R 1 = 1 [Alarm] Code Error 1000
R 10 = 1.0°c [Temperature] Room 2112
R 10 = 1.0°c [Temperature] Outdoor 2111
R 10 = 1.0°c [Temperature] Supply 2113
R 10 = 1.0% [Relative Humidity] Outdoor 2121
R 10 = 1.0 g/Kg [Absolute Humidity] Outdoor 2123
R 10 = 1.0% [Relative Humidity] Room 2122
R 10 = 1.0 g/Kg [Absolute Humidity] Room 2124
R 1 = 1% [% of opening] Register of fresh air 2413
R 1 = 1% [% of opening] Valve gas 2618
R 1 = 1% [% of opening] Electrical heaters (Triac) 2627
R 1 = 1% [% of opening] Hot water coil 2633
