IOM / ROOFTOP BALTIC Series - 0704-E Page 141
BEC
31
2
-B14
-BT12
-MS1
H
DN 20
DN 20
DN 20
DN 25
DN 25
DN 25
DN 20
20
50
45
40
35
30
25
-YV2
03
70
60 DN 25
DN 25
HOT WATER COIL DIAGRAM
NOTA :
MAXIMUM WORKING PRESSURE : 8 bar
MAXIMUM WORKING TEMPERATURE : 110°C
HOT WATER
PIPE DIAMETERS
