control interfaces ds50 menu tree
Main Screen Code Description Code Description Code Description Code UNIT Min Factory Max
1-Alarm 1000 # 1100 # 1110 # 1111
2-Data 2000 1-General 2100 1-Temperature 2110 Outside 2111 °c
Room 2112 °c
Supply 2113 °c
Return 2114 °c
2-Humidity 2120 Outside 2121 %.
Room 2122 %.
Outside 2123 g/Kg
Room 2124 g/Kg
3-Other 2130 Air Pres. 2131 pa
CO2 2132 ppm
Sw On/Off 2133 On/Off
Sw Reset 2134 On/Off
Sw Unoc. 2135 On/Off
4-Out. Custom. 2140 BM50.1 2141 On/Off
BE50.1 2142 On/Off
BE50.2 2143 On/Off
BE50.3 2144 On/Off
BE50.4 2145 On/Off
5-In. Custom. 2150 BM50.1 2151 On/Off
BM50.2 2152 On/Off
BE50.1 2153 On/Off
BE50.2 2154 On/Off
BE50.3 2155 On/Off
BE50.4 2156 On/Off
6-In.% Custom. 2160 BE50.1 2161 °c
BE50.2 2162 °c
BE50.3 2163 °c
BE50.4 2164 °c
BE50.1 2165 %.
BE50.2 2166 %.
BE50.3 2167 %.
BE50.4 2168 %.
2-Control 2200 1-Room 2210 Sp Cool 2211 °c
Sp Heat 2212 °c
Capa Cool 2213 %
Capa Heat 2214 %
Sw Dis.Cool 2215 On/Off
Sw Dis.Heat 2216 On/Off
2-Reheat 2220 Set Point 2221 °c
Capacity 2222 %
3-Humidity 2230 Sp Dehu 2231 %
Sp Humi 2232 %
Capa Dehu 2233 %
Capa Humi 2234 %
4-TCB 2240 Sw G 2241 On/Off
Sw Y1 2242 On/Off
Sw Y2 2243 On/Off
Sw W1 2244 On/Off
Sw W2 2245 On/Off
Sw B 2246 On/Off
