1140 Keyboard
For access, remove these FRUs in order:
v “1010 Battery pack” on page 78
v “1030 Optical drive or travel cover” on page 80
v “1100 Palm rest assembly with cables” on page 93
Table 23. Removal steps of keyboard
1
1
Step Screw (quantity) Color Torque
1 M2 × 5 mm, wafer-head, nylon-coated (1) Black 0.181 Nm
(1.85 kgfcm)
100 ThinkPad Edge 14″, Edge 15″, E40, and E50 Hardware Maintenance Manual
