Rear view
1 Sleep (standby) status indicator
Note: For the description of the indicator, see “Status indicators” on page
69.
2 Combo audio jack
3 HDMI port
4 RJ-45 (Ethernet) connector
5 eSATA/USB connector
6 External monitor connector
7 Security keyhole
3
4
5
6
2
1
7
Bottom view
1 Battery pack
2 Battery pack latch
3 Thermal slot (DIMM, hard disk drive, fan assembly)
4 ExpressCard slot
5 Wireless WAN card slot
6 Media Card Reader
1
2
3
4
5
6
Locations 133
