1050 Hard disk drive (HDD) assembly
For access, remove these FRUs in order:
v “1010 Battery pack” on page 78
v “1040 Thermal cover” on page 81
Table 12. Removal steps of HDD assembly
1
When installing: Make sure that the HDD connector is attached firmly.
Attention:
v Do not drop the drive or apply any physical shock to it. The drive is
sensitive to physical shock. Improper handling can cause damage and
permanent loss of data.
v Before removing the drive, have the user make a backup copy of all the
information on it if possible.
v Never remove the drive while the computer is operating or is in suspend
mode.
82 ThinkPad Edge 14″, Edge 15″, E40, and E50 Hardware Maintenance Manual
