Used to send video and audio signals from your computer to another audio or video device, such as a high-
performance monitor.
6 Ethernet connector
Used to connect an Ethernet cable for network access.
7 Power adapter connector
Used to connect the power adapter to your computer for power supply.
8 Security-lock slot
Used to secure a Kensington-style cable lock.
9 VESA threaded holes
Used to connect the matched VESA mount with the matched screws when you install the computer on the
wall. When you need to install the computer onto the ceiling or the wall, install four M4 x 10 mm screws there.
Note: Before connecting to the VESA mount, attach a mounting pad with 2.6 mm thickness to each screw
hole on the VESA mount.
10 Optical drive activity indicator (optional)
This indicator is on when the optical drive is in use.
11 Optical drive eject/close button (optional)
Used to eject the tray of the optical drive. After you insert a disc into the tray, press the eject/close button to
close the tray.
System board
Note: See “Front view” and “Rear view” for additional component descriptions.
4
V530-24ICB AIO User Guide and Hardware Maintenance Manual
