Appendix
Parallel operation of AIF and FIF interfaces
12
l
126
EDSMF2133IB EN 5.0
12 Appendix
12.1 Parallel operation of AIF and FIF interfaces
) Note!
The option of parallel operation ...
ƒ of a communication module (AIF) and a function module (FIF) exists for the
standard devices 8200 vector and Drive PLC.
ƒ of two function modules (FIF) exists for the standard devices 8200motec,
Drive PLC and starttec.
Notes on parallel operation
Attach/detach the communication module to/from the AIF interface. This is also possible
during operation.
0
8200vec073
For internal voltage supply, you must set jumper 0 at the indicated position.
External voltage supply (delivery state) Voltage supply through internal voltage source
0
0
